Lightest 4x4 Winch
The 12K winch, synthetic rope, control box, mounting bolts & fairlead weigh a total of 23.45kg
6.2HP Motor with 216:1 Gear Ratio
The reliable 6.2HP motor and tough 3 stage planetary gearbox will get you back on your journey
IP68 Waterproof
Stress free river crossings and mud runs due to a newly upgraded rating of IP68
Get a Winch You Can Trust
• Lifetime Mechanical Warranty
• 5 Year Electrical Warranty
• 5 Year Water Ingress Protection Warranty
Carbon Offroad
Carbon 12K - 12000lb Winch V3
from $1,049.00
$1,200.00
Carbon Winch 12k 12000lb Electric 12v 4x4 WinchVersion 3 - Now IP68 Waterproof5 Year Australian WarrantyLightest 4x4 Winch
Due to strong customer demand the Carbon Winch range has gone ALL BLACK.
The all new feature packed Ver 3 12000lb Winch from Carbon Offroad delivers a 4WD winch package boasting many extras to make the installation and use of your winch that much easier.
The Carbon Winch features a newly upgraded rating of IP68, so your river crossings and mud runs are stress free, featuring a breathable membrane style motor breather for heat expansion and contraction. The Carbon Winch gets your recovery done with ease by using the wireless or wired remote (both included) from the safety and convenience of your driver's seat.
IP68 meaning - Ingress Protection6 - Can withstand dust and dirt8 - Can be submerged under freshwater for 30 minutes up to 1.5m depth, but not during operation.
You want the reliability of a winch that will perform when you need it to, time after time.
The Carbon Winch is a proven performer with year on year sales growth and countless recoveries from the mud bogs of Tassie to the river crossings of the Cape. For peace of mind it's backed here in Australia by a class leading 5 year water ingress & electrical warranty and a lifetime geartrain warranty. We also stock a warehouse of replacement parts here in Australia to get you back winching if the need arises.
If you're capable with a few basic tools, installing a Carbon Winch is easy, with step by step instructions and many extras included to get the job done. We also thought of your safety by including an isolator switch with extra cabling, so when you're not using your winch it's safely turned off and no live power wires are at the front of your vehicle.
Mounting the control box is easy with a multi fit system that can either be mounted on the winch, above the winch drum or motor. Or with the bracket can be mounted to the vehicle or on top of your bullbar. As you know, "looks" are a big part of any 4x4 build, so we have included in your winch kit an ultra sexy CNC'd anodised alloy signature Carbon fairlead paired with our own robust designed hook that makes you stand out from the crowd. Weight is a serious consideration with all 4wd accessories, the Carbon Winch is super lightweight at only 19.0kg
Carbon Winches 12K Winch is a 12000lb line pull winch and can meet the rugged demands of off-road and utility use in Australian conditions. It is designed to deliver the best value, reliability and service life for a winch user.
Get a winch you can trust - Get a Carbon Winch
Winch Features
- Designed by an Australian offroad business for the harsh Aussie and international conditions
- IP68 rated fully sealed to resist water, dirt and dust ingress into motor, drum and gearbox mechanisms
- 12000lb pulling power with a fast line pull ratio of 216:1 using a triple planetary gear set
- 6.2HP series wound 12 volt electric motor (24 volt option)
- Wireless remote control unit with a lanyard - FULLY SEALED RECEIVER UNIT built into the control box. Simple to activate by holding both buttons down for 3 seconds to activate the remote control and turns off after 90 seconds of inactivity.
- The rotating ring gear clutch design minimises freespool drag and completely eliminates clutch engagement issues.
- Electroplated planetary gear sets for long life
- 3 layer membrane breather unit pre-fitted to the electric motor to allow condensation to evaporate and equalise pressure during heat cycles
- Multi Fit Fairlead - there is no need to worry about which suits your bullbar! Simply install as standard fitment or move up to offset the rope outlet by 20mm
- Fully zinc electroplated internals for corrosion protection
- High performance motor brushes with copper impregnated contacts and corrosion plated brush mounts
- Smooth ball bearing motor operation with a fully balanced motor armature for superior performance
- Superior holding power by utilising a hoist style brake unit mounted to the drum end plate which applies mechanical braking through the gear train with no heat generated in the drum. No contact to the drum means there is no risk of heat damage to the synthetic rope
- 4 position mounting for the control box bracket over the motor; over the drum, on top for flat mounting plates or in front of the winch for the top mounting control box when the winch is mounted vertically. Alternatively, 500mm cables allow remote mounting of the control box separately to the winch
What's in the Box
- 1 x Carbon 12K winch
- 24m x 10mm high strength synthetic winch rope
- 1 x Carbon winch hook
- 1 x 600A solenoid box Inc - all battery cables, wireless remote receiver, multi-fit mount
- 1 x Long black battery cable
- 1 x Wireless remote
- 1 x Wired remote
- 1 x Multifit CNC Alloy fairlead (offset and standard position)
- 4 x Mounting bolts
- 3 x Allen keys
- 2 x Additional longer mounting bolts (fairlead mounting)
- 2 x Additional nuts for remote mounting solenoid box
- 1 x Hook hand saver strap
- 1 x Carbon lanyard
- 1 x Carbon stubby cooler
- 1x Installation manual
12K Spare Parts
Carbon Offroad
Carbon Offroad Battery Isolator Switch
$37.50
Protect your battery and prevent electrical drain with our high-performance battery isolator switch. Ideal for vehicles and boats, this durable switch offers easy operation and versatile compatibility.
Kit Includes:
Battery Isolator Switch
4 x mounting bolts with nuts
Current & Voltage
On/Off 2 positions, 275 A continuous at DC 12V, 455 A intermittent at DC 12V, 1250 A momentary at DC 12V.
Simple Operation
The switch can be disconnected and reconnected by simply turning the knob and is supplied with bolts.
Sturdy Construction
The switch is made of ABS plastic housing and solid brass nut, rust-proof, corrosion-resistant, durable, and safe to use.
Great Compatibility
The battery switch used on DC 12 – 48 V systems to isolate and secure the electrical system.
Safety Protection
The battery switch eliminates any drain on the battery and safely disconnects it when the vehicle or boat is not in use.
Specs:
Max Current: 275AMax Voltage: 48VSwitch Function: ON-OFFTermination Stud Size: 3/8" (10mm) x 2Operating Temperature: −25°C~85°CHousing Colour: BK-Black
Carbon Offroad
Carbon Winches Wired Remote Control Plug Extension Kit -Suit V2 and V3
$34.99
Carbon Winches Australia - Winch control box wired remote mounted plug extension lead to suit July 2021-On winch - V2 and V3
THIS WILL ONLY SUIT V2/V3 WINCHES, IF UNSURE PLEASE CALL TO CHECK
If you have hidden your control box inside your bullbar, or have a bumper replacement bullbar such as a GM Fab bar or Rhino bar and cannot easily access your control box to plug in the hand remote, use this product to remotely mount the plug, either on your bumper or inside your engine bay. Such a simple item makes plugging in your wired controller a breeze. One less stress when out on the track, as guaranteed, when the wired controller comes out, you will most likely be wanting to think about more important things like is my rig filling up with bog hole water as I try and plug this controller in!
Extension is approximately 1450mm long.
Carbon Offroad
Carbon Winches Australia 600amp Sealed Winch Solenoid 12 Volt
$95.00
Carbon Winches Australia Fully Sealed Solenoid - 600amp peak rating
Our solenoid is supremely reliable. With zero warranties or failures since its release, you can be sure this solenoid unit will do the job for your winching duties.
Carbon Offroad
12 Volt Winch Control Box V2 - Complete with wireless controller
$199.00
$249.00
This is a 12 volt winch replacement CONTROL BOX, COMPLETE with WIRELESS CONTROLLER. Suitable for CW-12k, CW-95P and CW-17K models only.
The Carbon Offroad 12 volt control box and is an advanced, modern and powerful replacement for your original winch control. This device incorporates a wireless remote that gives you the ability to stay in the cab of your truck but still have complete control over activating or deactivating on site. The carbon offroad 12 volt "control box" also ensures a precise, even amount of power used for every pull as opposed to just one strong one. And unlike the old-fashioned cable, you never have to risk getting tangled from ground level again!
