The Lightest 12,000lb Winch
9K | 10K | 12K | 15K | 20K
3K | 4.5K | 6K
The Carbon 12K.
12,000lb Winch
IP68 Waterproof
6.2HP Motor (12V/24V)
3 Stage Planetary 216:1 Gearbox
Wired and Wireless Remote Included
Choose your hook colour!
Carbon Offroad 12K is a versatile powerhouse designed to tackle Australia’s
toughest challenges with ease.
With a 6.2HP motor and a 216:1 gearbox, the Carbon CW-12KV3 is engineered to handle the most demanding tasks.
Carbon Offroad
Carbon Scout Pro - 9000lb Winch V3
$1,149.00
$1,300.00
The Carbon Offroad Scout Pro Extreme Duty Performance Series winches are built with the frequent use winching user in mind who is tackling harsh offroad conditions on a regular basis, or the owner of vehicles which are extremely heavy, kitted out or towing in offroad conditions.
With larger modulus gearsets, increased motor horsepower and standard inclusions from our premium accessory range including the Mega-Pro Winch Rope Thimble and Mega-Pro Premium Fairlead, you are getting a best of the best package straight out of the box.
The Scout Pro series winches share the same 2023 Version 3 Winch Chassis as our tried and tested 12K winch. This allows fitment into most larger 4x4 utes and 4x4 Wagons. Due to the longer 7.0HP Motor, you should consult the technical drawing to determine clearance and fitment length on your winch mount. Most larger vehicles such as RAM, F-Truck and Silverado are generally wide enough to not be a problem, Fitment to any dual cab, 70 series, 200 series or any other similar sized 4wd wagon should be confirmed prior to purchase. The responsibility of the fitment is that of the end-user or installer.
The 9000lb winch comes with 10mm high density pre stretched premium UHMWPE winch rope rated at a whopping 9000kg minimum breaking strain.
Carbon Winch 2023 V3 winch chassis
7.0HP Motor
104:1 heavy duty performance gearbox
10mm Synthetic Rope with HD braced rope thimble
Carbon Offroad MEGAPRO Premium CNC billet type 3 hard anodised multi position fairlead
Carbon Offroad MEGAPRO 16 tonne soft shackle compatible winch rope thimble
The high performance heavy duty upgraded solenoid unit in this winch is rated to 100amps more than the CW-12K solenoid unit.
Carbon Offroad
Carbon Scout Pro - 10000lb Winch V3
$1,049.00
$1,249.00
Got a bar rated to 10K? Stay within spec and retain your warranty with the compact Carbon XD10.
The Carbon Offroad Scout Pro Extreme Duty Performance Series winches are built with the frequent use winching user in mind who is tackling harsh offroad conditions on a regular basis, or the owner of vehicles which are extremely heavy, kitted out or towing in offroad conditions.
With larger modulus gearsets compared to our CW-12K and standard inclusions from our premium accessory range including the Mega-Pro Winch Rope Thimble and Mega-Pro Premium Fairlead, you are getting a best of the best package straight out of the box.
Did you Know: "Module" is the unit of size that indicates how big or small a gear is. It is the ratio of the reference diameter of the gear divided by the number of teeth.
Carbon Offroad
Carbon Scout Pro - 15000lb Winch V3
$1,299.00
$1,475.00
Carbon Offroad Scout Pro 15K is a powerhouse engineered to bridge the gap between ute-sized winches and truck-grade brutes.
With a formidable 15,000lb pulling capacity, the Carbon CW-XD15 combines a 7 HP series-wound motor, oversized modulus gearsets, and a heavy-duty solenoid rated 100 amps higher than the 12K’s to deliver relentless pulling power run after run.
Do you haul slide-on campers? Tow heavy trailers through sand? Drive a fully kitted 79 Series, RAM 1500, or LandCruiser wagon that tips the scales beyond a 12K’s comfort zone? If your rig needs more muscle without jumping to a 20K truck winch, this is the winch you need.
Packed straight out of the box with premium kit:
Mega-Pro billet fairlead
Forged rope thimble
24 m of 11 mm high density pre stretched premium UHMWPE rope rated at a whopping 9000kg minimum breaking strain.
The Scout Pro 15K delivers the strength, durability, and confidence you need to conquer serious recoveries and keep the adventure moving.
Carbon Offroad Scout Pro Extreme Duty Performance Series winches are built with the frequent use winching user in mind who is tackling harsh offroad conditions on a regular basis, or the owner of vehicles which are extremely heavy, kitted out or towing in offroad conditions.
Did you Know: "Module" is the unit of size that indicates how big or small a gear is. It is the ratio of the reference diameter of the gear divided by the number of teeth.
The Scout Pro series winches share the same 2023 Version 3 Winch Chassis as our tried and tested 12K winch. This allows fitment into most larger 4x4 utes and 4x4 Wagons. Due to the longer 7.0HP Motor, you should consult the technical drawing to determine clearance and fitment length on your winch mount. Most larger vehicles such as RAM, F-Truck and Silverado are generally wide enough to not be a problem, Fitment to any dual cab, 70 series, 200 series or any other similar sized 4wd wagon should be confirmed prior to purchase. The responsibility of the fitment is that of the end-user or installer.
Carbon Offroad
Carbon Scout Pro - 15000lb Winch V3 24V
$1,549.00
$1,750.00
Please note this item is a custom build and my take up to 14 days to dispatch.
The Carbon Offroad Scout Pro Extreme Duty Performance Series winches are built with the frequent use winching user in mind who is tackling harsh offroad conditions on a regular basis, or the owner of vehicles which are extremely heavy, kitted out or towing in offroad conditions.
With larger modulus gearsets compared to our CW-12K, increased motor horsepower and standard inclusions from our premium accessory range including the Mega-Pro Winch Rope Thimble and Mega-Pro Premium Fairlead, you are getting a best of the best package straight out of the box.
Did you Know: "Module" is the unit of size that indicates how big or small a gear is. It is the ratio of the reference diameter of the gear divided by the number of teeth.
The Scout Pro series winches share the same 2023 Version 3 Winch Chassis as our tried and tested 12K winch. This allows fitment into most larger 4x4 utes and 4x4 Wagons. Due to the longer 7.0HP Motor, you should consult the technical drawing to determine clearance and fitment length on your winch mount. Most larger vehicles such as RAM, F-Truck and Silverado are generally wide enough to not be a problem, Fitment to any dual cab, 70 series, 200 series or any other similar sized 4wd wagon should be confirmed prior to purchase. The responsibility of the fitment is that of the end-user or installer.
The 15000lb winch comes with 11mm high density pre stretched premium UHMWPE winch rope rated at a whopping 9000kg minimum breaking strain.
The high performance heavy duty upgraded solenoid unit in this winch is rated to 100amps more than the CW-12K solenoid unit.
Carbon Offroad
Carbon Scout Pro - 20000lb Extreme Duty Truck Winch
$1,999.00
Introducing the Carbon Offroad Extreme Duty Scout Pro 20K Truck Winch, engineered to deliver exceptional performance and reliability in the most demanding environments.
Are you ready to take your offroad adventures to the next level? Look no further than the Carbon Offroad Scout 20K, a powerhouse designed to tackle the toughest challenges with ease. With a massive 20,000 lbs of pulling capacity, the Carbon CW-XD20 is engineered to handle the most demanding tasks. Whether you're hauling heavy trailers, or recovering heavy vehicles or tackling extreme terrain this winch has the power to get you through. If you own a large offroad vehicle, this is the winch you've been waiting for. With its unmatched power, durability and safety features, it is the perfect tool to conquer any terrain and make your offroad adventures unforgettable.
Powerful Performance: The series-wound motor generates 7HP.
Reliable and Durable: The three-stage planetary gearbox provides unmatched durability and reliability, even under the harshest conditions.
Enhanced Safety: The automatic brake system within the motor frame eliminates the risk of overheating and ensures maximum safety by applying consistent, proportional braking force to the rope based on the load.
Easy Operation: The rotating ring gear clutch allows for effortless switching between freespool and engaged modes.
Versitile Control: Wired and wireless remote control options offer convenient and flexible operation.
Rubust Construction: The 600A sealed solenoid guarantees reliable and long lasting performance.
37.2kg installed weight
Carbon Offroad
Carbon Scout Pro - 20000lb Extreme Duty Truck Winch 24V
$1,999.00
Introducing the Carbon Offroad Extreme Duty Scout Pro 20K Truck Winch, engineered to deliver exceptional performance and reliability in the most demanding environments.
Are you ready to take your offroad adventures to the next level? Look no further than the Carbon Offroad Scout 20K, a powerhouse designed to tackle the toughest challenges with ease. With a massive 20,000 lbs of pulling capacity, the Carbon CW-XD20 is engineered to handle the most demanding tasks. Whether you're hauling heavy trailers, or recovering heavy vehicles or tackling extreme terrain this winch has the power to get you through. If you own a large offroad vehicle, this is the winch you've been waiting for. With its unmatched power, durability and safety features, it is the perfect tool to conquer any terrain and make your offroad adventures unforgettable.
Powerful Performance: The series-wound motor generates 7HP.
Reliable and Durable: The three-stage planetary gearbox provides unmatched durability and reliability, even under the harshest conditions.
Enhanced Safety: The automatic brake system within the motor frame eliminates the risk of overheating and ensures maximum safety by applying consistent, proportional braking force to the rope based on the load.
Easy Operation: The rotating ring gear clutch allows for effortless switching between freespool and engaged modes.
Versitile Control: Wired and wireless remote control options offer convenient and flexible operation.
Rubust Construction: The 600A sealed solenoid guarantees reliable and long lasting performance.
37.2kg installed weight
ATV/SXS
Carbon Offroad
Carbon 3.0k 3000lb ATV/Trailer Winch
$349.00
$425.00
Carbon CW-3U 3000lb Light-Duty Trailer & Utility Winch
The Carbon CW-3U 3.0K 3000lb Winch delivers exceptional value, combining reliability and premium quality in a compact design. Built for light-duty applications with a 3,000 lb (1360 kg) capacity, this winch is engineered to handle a variety of towing and utility tasks effortlessly.
Designed with convenience in mind, it features both a handheld remote and a wireless remote control, allowing seamless operation of the power-in/power-out functions. Enhanced with tie rods for added stability, the CW-3U ensures durability and performance when you need it most.
Key Features & Specifications:
Rated Line Pull: 3,000 lbs (1360 kg), single-line
Motor: 12V DC, 1.5 HP Permanent Magnet Motor
Remote Controls:
Wired remote with 12 ft (3.7m) lead
Wireless remote included
Geartrain: Single-stage planetary
Gear Ratio: 153:1
Clutch (Free-Spooling): Split ring gear
Brake System: Self-locking gear train (rated load holding)
Drum Dimensions: 1.26” diameter × 2.87” length (32mm × 73mm)
Synthetic Rope: 43 ft, 3/16” diameter (13m, 4.8mm)
Fairlead: Roller
Mounting Bolt Pattern: 3.0” × 4.87” (76mm × 124mm)
Winch Dimensions: 12.2” × 5.0” × 5.0” (310mm × 127mm × 127mm)
Packing Dimensions: 15.7” × 7.9” × 8.7” (400mm × 200mm × 220mm)
Shipping Weight: 22 lbs (10 kg)
Warranty: 1 year
The Carbon CW-3U is an excellent choice for small trailers, ATVs, and light-duty applications, offering smooth operation, powerful performance, and reliability in a compact package.
Upgrade your towing experience with the Carbon CW-3U Winch today!
12V DC PERFORMANCE SPECS (first layer of drum)
Line PullLbs.(Kgs.)
Line SpeedFT./min(M/min.)
MotorCurrent
Pull by layerlayer/Lbs(Kgs.)
0
20.4(6.2)
10Amps
1/3000(1360)
1000(453)
14.2(4.3)
65Amps
3/2725(1235)
2000(907)
10.9(3.3)
96Amps
3/2480(1125)
3000(1360)
7.7(2.4)
Carbon Offroad
Carbon 4.5k 4500lb ATV/Trailer Winch
$474.00
$550.00
Carbon Offroad 4,500 lb ATV/UTV Winch – Compact, Powerful, and Versatile
Upgrade your off-road adventures and heavy-duty tasks with the Carbon Offroad 4,500 lb Capacity Winch, designed for ATVs, UTVs, side-by-sides, car trailers, and equipment transport.
Enhanced Design & Performance
Since September 2021, this winch has been redesigned for superior durability and ease of use, featuring:
Improved clutch handle operation for smoother control
Enhanced sealing for wet and rugged conditions
Upgraded components & finish for long-lasting performance—all at the same great price
Compact & Easy to Mount
Integrated mounting plate for quick and simple installation
Compatible with trailers, ATVs, and buggies
Easily secures to an existing pedestal or designated winch mount
Wireless Control for Maximum Convenience
Includes free wireless remote control for effortless operation
Also features a handlebar mini-rocker switch for direct control from your ATV
Versatile Applications
Ideal for a wide range of uses, including:
Small car and equipment trailers
Loading heavy equipment into vans
Retrieving stuck ATVs, UTVs, or buggies
Pulling boats (tinnies) onto trailers
Opening cattle gates on livestock trucks
Key Features:
4,500 lb (2,040 kg) line pull for strong and reliable performance
Power in & out operation with load-holding and dynamic braking
Sealed permanent magnet motor for high efficiency with low amp draw
Full metal 3-stage planetary gear train for greater pulling force and durability
Synthetic rope for lightweight, high-strength, and safer winching
Aluminium Hawse fairlead to reduce friction and extend rope life
Specifications:
Model: CW-45
Rated Line Pull: 4,500 lbs (2,040 kg)
Motor: 12V DC, 1.9HP
Remote Control: Handlebar Mini-Rocker & Wireless Remote (included)
Geartrain: 3-Stage Planetary, 176:1 ratio
Brake: Dynamic & Mechanical
Synthetic Rope: 43’ (13m) x 1/4” (6.35mm)
Mounting Bolt Pattern: 3.0” x 6.59” (76mm x 167mm)
Winch Dimensions: 14.9” x 4.7” x 4.5” (379mm x 120mm x 115mm)
Shipping Weight: 12.2 kg
This rugged, compact, and high-performance winch is a must-have for anyone looking to tackle tough terrains or simplify heavy lifting.
Get yours today and make every job easier!
12V DC PERFORMANCE SPECS (first layer of drum)
Line Pull
Lbs.(Kgs.)
Line Speed
FT./min(M/min.)
MotorCurrent
Pull by layerlayer/Lbs(Kgs.)
0
20.4(6.2)
31 Amps
1/4500(2040)
1000
14.2(4.3)
65Amps
2/3750(1700)
2000
10.9(3.3)
96Amps
3/3510(1595)
3000
7.7(2.4)
125Amps
4/3300(1500)
4500
4.9(1.5)
175.Amps
Carbon Offroad
Carbon Offroad 6000lb ATV/Small 4X4 Winch
$599.00
$700.00
The Carbon Offroad 6000 lb ATV winch for ATVs, small 4wds, caravans, trailers, boats.
A small compact winch with integrated mounting plate makes mounting this winch is as simple as it can get to an existing pedestal on a trailer, or into a winch location on an small form factor bar. With wireless and wired remote control included free, it's a very versatile winch setup. Perfect for small car and equipment trailers, great to mount in the back of a van to help load heavy equipment and has even been used to load tinny's and open cattle gates on Livestock Truck Trailers. A great small all rounder winch to make work easier or to get your Jimny or trailer out of the bog.
Features and Benefits
Sealed motor and geartrain allows for flawless operations in extreme conditions
Permanent magnet motor provides heavy duty torque for increased pulling power
Cam action disengages gears for near silent free-spooling
Mechanical and dynamic brake offers increased control and prevents rollback
24V DC PERFORMANCE SPECS (first layer of drum)
Line Pull
Lbs.(Kgs.)
Line Speed
FT./min(M/min.)
MotorCurrent @24V
0 (0)
20.5 (6.2)
15 Amps
1000 (454)
16.1 (4.9)
41 Amps
2000 (907)
12.8 (3.9)
68 Amps
3000 (1361)
10.7 (3.3)
84 Amps
4000 (1814)
8.6 (2.6)
116 Amps
6000 (2721)
4.9 (1.5)
160 Amps
**The manual indicates that a circuit breaker is included, unfortunately this is not the case. We apologise for any confusion.**
Carbon Offroad
Carbon Offroad Long Drum 6000lb ATV/Small 4X4 Winch
$659.00
$775.00
Carbon Offroad Long Drum 6K is a nimble workhorse created to reach where short-drum winches can’t.
With 6,000 lbs of pulling capacity and a generous 26m synthetic rope on its extended drum, the Carbon CW-XD6L is engineered for versatile duty on ATVs, compact 4WDs, caravans, trailers and boats. Do you need to haul a tinny up a steep, low-tide ramp? Slide heavy machinery into a van from well outside the rear doors? Winch a small 4WD or camper-trailer through deep sand without adding an extension rope? If your jobs demand extra line reach in tight spaces, this is the winch you’ve been waiting for. With a sealed permanent-magnet motor, near-silent free-spooling clutch, dual wired + wireless remotes and fail-safe braking, the Long Drum 6K delivers reliable power, precise control and the rope length to keep work sites—and weekend getaways—running smoothly.
Sealed motor and geartrain allows for flawless operations in extreme conditions
Permanent magnet motor provides heavy duty torque for increased pulling power
Cam action disengages gears for near silent free-spooling
Mechanical and dynamic brake offers increased control and prevents rollback
