Check your winch before every trip by cleaning and all terminals, testing the isolator switch, running the full rope out to inspect for burrs, cuts, dirt and sand, checking the free spool lever moves freely, then re-spooling the rope back on under light load. The re-spool warms the motor and gearbox and lays the rope evenly on the drum.

That whole sequence takes about twenty minutes in the driveway. It is the difference between a winch that works when you're buried to the axles and one that clicks, groans and does nothing.

A winch is an insurance policy. You buy it hoping you never need it, and the only moment that matters is the moment you claim on it. Usually in mud, usually at dusk, usually a long way from a tow truck. The problem with insurance policies is that they quietly lapse. Terminals corrode. Rope picks up grit. A remote sits in the glovebox for eight months with a flat battery in it. None of that shows up until you press the button.

These checks apply to any electric winch, whatever badge is on it, whether that's Carbon, Warn, Runva, Domin8r or a no-name unit that came with the bar. The hardware differs; the failure modes don't. If you're shopping rather than servicing, our range of 4x4 winches is here.

The checklist

1. Clean and tighten the electrical terminals

A winch pulls an enormous amount of current out of your battery, far more than anything else on the vehicle. [CONFIRM: peak current draw, e.g. "up to XXX amps at full load"]. Anything that adds resistance in that circuit costs you pulling power and generates heat where you don't want it.

Grab the right size spanner and check both terminals, negative and positive, at the winch and at the battery. You're checking two things: that the connection is clean, and that it's tight. Corrosion is the obvious enemy, but a loose terminal is worse, because it arcs under load.

If you find green or white powder on the terminal, disconnect it, clean the post and the eyelet back to bare metal with a wire brush, reconnect and tighten. A smear of terminal grease afterwards keeps moisture out.

2. Test the isolator switch

A winch isolator switch lets you cut power to the winch completely when you're not using it. Worth having: it stops any chance of the winch running away on a stuck solenoid while you're driving, and it means a chafed cable can't quietly cook itself against the chassis.

If you run one, check it switches cleanly and actually kills power. Turn it on before you start testing. An isolator you've forgotten to switch on is the single most common reason a winch appears dead.

3. Run the rope out and inspect the whole length

This is the check most people skip, because it means unspooling the entire rope. Do it anyway. Rope damage doesn't happen at the end you can see. It happens at whatever section was dragging across a rock ledge on your last trip, which is now buried three layers down on the drum.

Run the rope out and work along it looking for:

• Burrs, nicks and cuts. Anywhere the outer fibres or wires have been severed.
• Flat spots or glazing. Heat damage, usually from friction under load.
• Embedded dirt and sand. Grit acts like sandpaper inside a synthetic rope, cutting it from the inside on every wrap.
• Broken strands on steel cable, or a fuzzy, furred section on synthetic.

Synthetic rope hides damage better than steel and takes grit worse. If yours is full of sand, wash it in clean fresh water and let it dry fully before it goes back on the drum. [CONFIRM: your replacement threshold]. If you're unsure, replace it. A rope is a fraction of the cost of what it's attached to, and a synthetic rope that fails under load is far safer than steel but still not something you want happening near your bonnet.

4. Check the free spool lever

The engage or free spool lever declutches the drum from the gearbox so you can pull rope out by hand. On most bullbar installs it sits on the end of the winch housing, which means it lives in the direct line of fire for mud, sand and stone chips.

Work it through its full travel. It should move under light hand pressure and engage positively at both ends. If it's stiff, gritty or vague, clean around the shaft and check it isn't seized. A free spool lever that won't engage means a winch that spins its motor and pulls nothing. Spare parts are here if something needs replacing.

5. Re-spool under light load

Now that the rope is off the winch, spool it back on under light load rather than free-running it. There are two reasons this step matters, and both of them are why the check is worth doing even if you found nothing wrong.

It warms the motor and gearbox. Running the winch circulates the gearbox lubricant and gets everything moving. A winch that hasn't turned in six months has oil sitting in the bottom of the housing.

It lays the rope evenly on the drum. Rope spooled back on under tension packs flat and tight, layer on layer. Rope that's been dragged back on loose builds up in ridges, and the next time you pull hard, it digs down between the loose wraps, jams, and can ride up against the drum flange. That's how you end up with a bird's nest at the exact moment you need a smooth pull.

Light load means exactly that. You want enough tension to keep the rope taut, nothing more. Walk it back with a gloved hand on the rope, or hook to a tree with a little resistance on the strap. You are not testing pulling capacity here. If the winch is new, read our first use guidelines before the first real recovery.

The bonus is that by the end of this step you've also confirmed your remote control works, which is the other thing that quietly dies in a glovebox.

One more tip: carry a spare remote battery

Keep a spare battery for your winch remote in the vehicle. It's a two-dollar part that turns a dead winch back into a working one, and it's the least glamorous, highest-value thing in this entire article.

How often should you do this?

The three-month interval is the one people ignore. A winch that sits unused for a year is more likely to fail than one that gets worked regularly.

Frequently asked questions

How often should you run your winch?

At least once every three months, even if you're not going anywhere. Run the rope out and re-spool it under light load. This circulates the gearbox lubricant, warms the motor, and confirms the winch and remote both still work. A winch that sits untouched for a year is more likely to fail than one used regularly.

Do you need to re-spool a winch rope under load?

Yes. Rope spooled back under light tension packs flat and evenly across the drum. Loosely wound rope builds ridges, and under a hard pull it digs down between the loose wraps and jams, or rides up against the drum flange. Light tension is enough. You're not testing capacity.

How do I know when to replace my winch rope?

Replace it if you find cuts, severed fibres, broken strands, flat or glazed sections from heat, or grit embedded through the rope that won't wash out. Synthetic rope damaged by sand degrades from the inside, so inspect the full length, not just the visible end. If you're unsure, replace it.

Why won't my winch free spool?

Usually a seized or partially engaged free spool lever, often from mud or grit around the shaft. Work the lever through its full travel and clean around it. If the lever moves freely but the drum won't declutch, the clutch mechanism itself needs attention. If the winch runs but the drum doesn't turn, the clutch isn't engaging.

Do I need a winch isolator switch?

It's not mandatory, but it's worth fitting. An isolator cuts power to the winch entirely when it's not in use, which prevents a stuck solenoid from running the winch unexpectedly and stops a damaged cable from carrying current where it shouldn't. If you fit one, check it works as part of your pre-trip routine.

Does this apply to any brand of winch?

Yes. Terminals, rope, free spool and even spooling are common to every electric winch, whatever the badge. Torque figures and rope replacement thresholds vary between manufacturers, so check your own manual for those.

Ready to fit a winch?

If your four-wheel drive doesn't have a winch yet, or you're replacing a tired one, start with our 4x4 winch range. Not sure what capacity you need? The short version is GVM × 1.5.

Thanks to the team at Mad Mates for the demonstration.
