Carbon Offroad
Carbon 3.0k 3000lb ATV/Trailer Winch
$399.00
Carbon CW-3U 3000lb Light-Duty Trailer & Utility Winch
The Carbon CW-3U 3.0K 3000lb Winch delivers exceptional value, combining reliability and premium quality in a compact design. Built for light-duty applications with a 3,000 lb (1360 kg) capacity, this winch is engineered to handle a variety of towing and utility tasks effortlessly.
Designed with convenience in mind, it features both a handheld remote and a wireless remote control, allowing seamless operation of the power-in/power-out functions. Enhanced with tie rods for added stability, the CW-3U ensures durability and performance when you need it most.
Key Features & Specifications:
Rated Line Pull: 3,000 lbs (1360 kg), single-line
Motor: 12V DC, 1.5 HP Permanent Magnet Motor
Remote Controls:
Wired remote with 12 ft (3.7m) lead
Wireless remote included
Geartrain: Single-stage planetary
Gear Ratio: 153:1
Clutch (Free-Spooling): Split ring gear
Brake System: Self-locking gear train (rated load holding)
Drum Dimensions: 1.26” diameter × 2.87” length (32mm × 73mm)
Synthetic Rope: 43 ft, 3/16” diameter (13m, 4.8mm)
Fairlead: ATV Fairlead
Mounting Bolt Pattern: 3.0” × 4.87” (76mm × 124mm)
Winch Dimensions: 12.2” × 5.0” × 5.0” (310mm × 127mm × 127mm)
Packing Dimensions: 15.7” × 7.9” × 8.7” (400mm × 200mm × 220mm)
Shipping Weight: 22 lbs (10 kg)
Fitted Weight: 19.8lb (9kg)
The Carbon CW-3U is an excellent choice for small trailers, ATVs, and light-duty applications, offering smooth operation, powerful performance, and reliability in a compact package.
Upgrade your towing experience with the Carbon CW-3U Winch today!
Carbon Offroad
Carbon Offroad 6000lb ATV/Small 4X4 Winch
$599.00
The Carbon Offroad 6000 lb ATV winch for ATVs, small 4wds, caravans, trailers, boats.
A small compact winch with integrated mounting plate makes mounting this winch is as simple as it can get to an existing pedestal on a trailer, or into a winch location on an small form factor bar. With wireless and wired remote control included free, it's a very versatile winch setup. Perfect for small car and equipment trailers, great to mount in the back of a van to help load heavy equipment and has even been used to load tinny's and open cattle gates on Livestock Truck Trailers. A great small all rounder winch to make work easier or to get your Jimny or trailer out of the bog.
Features and Benefits
Sealed motor and geartrain allows for flawless operations in extreme conditions
Permanent magnet motor provides heavy duty torque for increased pulling power
Cam action disengages gears for near silent free-spooling
Mechanical and dynamic brake offers increased control and prevents rollback
**The manual indicates that a circuit breaker is included, unfortunately this is not the case. We apologise for any confusion.**
Carbon Offroad
Carbon 4.5k 4500lb ATV/Trailer Winch
$499.00
Carbon Offroad 4,500 lb ATV/UTV Winch – Compact, Powerful, and Versatile
Upgrade your off-road adventures and heavy-duty tasks with the Carbon Offroad 4,500 lb Capacity Winch, designed for ATVs, UTVs, side-by-sides, car trailers, and equipment transport.
Enhanced Design & Performance
Since September 2021, this winch has been redesigned for superior durability and ease of use, featuring:
Improved clutch handle operation for smoother control
Enhanced sealing for wet and rugged conditions
Upgraded components & finish for long-lasting performance—all at the same great price
Compact & Easy to Mount
Integrated mounting plate for quick and simple installation
Compatible with trailers, ATVs, and buggies
Easily secures to an existing pedestal or designated winch mount
Wireless Control for Maximum Convenience
Includes free wireless remote control for effortless operation
Also features a handlebar mini-rocker switch for direct control from your ATV
Versatile Applications
Ideal for a wide range of uses, including:
Small car and equipment trailers
Loading heavy equipment into vans
Retrieving stuck ATVs, UTVs, or buggies
Pulling boats (tinnies) onto trailers
Opening cattle gates on livestock trucks
Key Features:
4,500 lb (2,040 kg) line pull for strong and reliable performance
Power in & out operation with load-holding and dynamic braking
Sealed permanent magnet motor for high efficiency with low amp draw
Full metal 3-stage planetary gear train for greater pulling force and durability
Synthetic rope for lightweight, high-strength, and safer winching
Aluminium Hawse fairlead to reduce friction and extend rope life
Specifications:
Model: CW-45
Rated Line Pull: 4,500 lbs (2,040 kg)
Motor: 12V DC, 1.9HP
Remote Control: Handlebar Mini-Rocker & Wireless Remote (included)
Geartrain: 3-Stage Planetary, 176:1 ratio
Brake: Dynamic & Mechanical
Synthetic Rope: 43’ (13m) x 1/4” (6.35mm)
Mounting Bolt Pattern: 3.0” x 6.59” (76mm x 167mm)
Winch Dimensions: 14.9” x 4.7” x 4.5” (379mm x 120mm x 115mm)
Shipping Weight: 12.2 kg
This rugged, compact, and high-performance winch is a must-have for anyone looking to tackle tough terrains or simplify heavy lifting.
Get yours today and make every job easier!
12V DC Performance Specs (First Layer of Drum)
Line Pull
Lbs.(Kgs.)
Line Speed
FT./min(M/min.)
MotorCurrent
Pull by layerlayer/Lbs(Kgs.)
0
20.4 (6.2)
31 Amps
1/4500 (2040)
1000
14.2 (4.3)
65 Amps
2/3750 (1700)
2000
10.9 (3.3)
96 Amps
3/3510 (1595)
3000
7.7 (2.4)
125 Amps
4/3300 (1500)
4500
4.9 (1.5)
175 Amps
Carbon Offroad
Carbon Offroad Long Drum 6000lb ATV/Small 4X4 Winch
$699.00
Carbon Offroad Long Drum 6K is a nimble workhorse created to reach where short-drum winches can’t.
With 6,000 lbs of pulling capacity and a generous 26m synthetic rope on its extended drum, the Carbon CW-XD6L is engineered for versatile duty on ATVs, compact 4WDs, caravans, trailers and boats. Do you need to haul a tinny up a steep, low-tide ramp? Slide heavy machinery into a van from well outside the rear doors? Winch a small 4WD or camper-trailer through deep sand without adding an extension rope? If your jobs demand extra line reach in tight spaces, this is the winch you’ve been waiting for. With a sealed permanent-magnet motor, near-silent free-spooling clutch, dual wired + wireless remotes and fail-safe braking, the Long Drum 6K delivers reliable power, precise control and the rope length to keep work sites and weekend getaways running smoothly.
Features
Sealed motor and geartrain allows for flawless operations in extreme conditions
Permanent magnet motor provides heavy duty torque for increased pulling power
Cam action disengages gears for near silent free-spooling
Mechanical and dynamic brake offers increased control and prevents rollback
Please note this kit does not include the winch cradle in the pictures.
Carbon Offroad
Carbon Offroad 6000lb ATV/Small 4X4 Winch 24V
$599.00
The Carbon Offroad 6000 lb ATV winch for ATVs, small 4wds, caravans, trailers, boats.
A small compact winch with integrated mounting plate makes mounting this winch is as simple as it can get to an existing pedestal on a trailer, or into a winch location on an small form factor bar. With wireless and wired remote control included free, it's a very versatile winch setup. Perfect for small car and equipment trailers, great to mount in the back of a van to help load heavy equipment and has even been used to load tinny's and open cattle gates on Livestock Truck Trailers. A great small all rounder winch to make work easier or to get your Jimny or trailer out of the bog.
Features and Benefits
Sealed motor and geartrain allows for flawless operations in extreme conditions
Permanent magnet motor provides heavy duty torque for increased pulling power
Cam action disengages gears for near silent free-spooling
Mechanical and dynamic brake offers increased control and prevents rollback
Australia's Trusted Store to Buy ATV Winch Online
Looking for the best place to buy ATV winch online in Australia? You've found it. At Carbon Offroad, we bring you strong, safe, and easy-to-use ATV winches that make every ride worry-free. Whether you use your ATV for work, play, or adventure, our winches are built tough for the Aussie outdoors.
Why Choose an ATV Winch?
An ATV winch is your best mate when the ground gets rough. Stuck in mud? Climbing over rocks? Pulling a gear or a trailer? A good winch makes it easy. It saves time, keeps you safe, and gives you peace of mind. With a winch, you can:
- Pull your ATV free from sand, snow, or mud
- Recover a mate's bike when they get stuck
- Tow small loads with ease
- Explore with more freedom, knowing you can get out of tough spots
Built Tough for Australian Conditions
Not all winches are the same. Cheap winches can fail when you need them most. That's why Carbon Offroad designs and tests every product for real Australian terrain. Our ATV winches are:
- Water resistant: Sealed motors keep out water and dirt
- Strong: Steel gears and synthetic ropes for max pull power
- Safe: Automatic brakes hold your load steady
-
Easy to use: Simple controls, with both wired and wireless options
Our ATV Winch Range
We have a winch for every job. When you buy ATV winch online in Australia from Carbon Offroad, you can choose from:
3,000 lb ATV/Trailer Winch
Perfect for smaller ATVs, trailers, and light recovery work. Compact, easy to mount, and reliable.
4,500 lb ATV/UTV Winch
A step up in strength. Great for mid-size ATVs and UTVs. Comes with wireless and handlebar remotes.
6,000 lb ATV / Small 4x4 Winch (12V)
For heavy-duty use. Strong pulling power, compact size, and built tough for bigger ATVs or small 4x4s.
6,000 lb ATV Winch Long Drum (12V)
Extra rope length for more reach. Ideal for steep climbs or tricky recovery spots.
6,000 lb ATV / Small 4x4 Winch (24V)
Same heavy-duty power, but built for 24V systems. Perfect for pro setups and long-lasting performance.No matter which one you choose, you'll get strength, safety, and Carbon Offroad quality.
Why Buy from Carbon Offroad?
We're more than a store - we're offroad people too. We know what works in the bush, on the beach, and in the outback. Here's why customers choose us when they buy ATV winch online in Australia:
- Trusted brand: 100% Australian-owned
- Expert support: Real advice from people who ride
- Fast shipping: Get your gear when you need it
- Warranty: Peace of mind with every winch
- Quality tested: Gear that's proven to perform
How to Choose the Right ATV Winch
Picking the right winch is easy when you know what to look for. Think about:
- Your ATV size – Bigger bikes need stronger winches.
- Your use – Light use? Go with 3,000 lb. Heavy use? Step up to 4,500 or 6,000 lb.
- Your setup – Check if your ATV runs on 12V or 24V.
- Your terrain – Mud, sand, rocks, or snow? Choose rope length and strength to match.
Easy to Buy, Easy to Use
When you buy ATV winch online in Australia from Carbon Offroad, the process is simple:
- Browse online: See all models with clear details.
- Pick your winch: Choose the right size and type.
- Order online: Secure checkout and fast delivery.
- Fit and ride: Install it, and you're ready for any adventure.
Order Your ATV Winch Today
Ready to upgrade your ride? Don't wait until you're stuck. Be ready now. When you buy ATV winch online in Australia from Carbon Offroad, you get gear that works when it matters most.Shop now. Get fast delivery. Ride with confidence.
