Carbon 4.5k 4500lb ATV/Trailer Winch

Name: Carbon 4.5k 4500lb ATV/Trailer Winch
Brand: Carbon Offroad
SKU: CW-45
Price: 499.0 AUD
Availability: InStock
Rating: 5.0 (5 reviews)

SKU: CW-45

$499.00

Carbon Offroad 4,500 lb ATV/UTV Winch – Compact, high-performance 12V winch with 3-stage planetary gearbox, synthetic rope, aluminium hawse fairlead, and wireless/handlebar controls. Ideal for trailers, ATVs, UTVs, and heavy-duty recovery.

Fast Shipping + Order tracking

100% Australian Owned

Free Extended Warranty

Quality Assured by Carbon Staff

Your Order Packed With Care

Main Features Dimensions Warranty

Rated Capacity: 3,000 lbs (1360 kg), single-line pull
Motor: 12V DC, 1.5 HP permanent magnet motor
Operation Modes: Wired remote with 12 ft (3.7 m) lead; Wireless remote included
Geartrain: Single-stage planetary
Gear Ratio: 153:1
Clutch: Split ring gear, free-spooling
Brake System: Self-locking gear train (rated load holding)
Durability Enhancements: Tie rods for stability
Rope Type: Synthetic rope, 43 ft × 3/16” (13 m × 4.8 mm)
Fairlead: Roller

Click here for an ATV Winch Dimension Comparison Chart

We stand behind the quality and performance of our products. All Carbon Offroad winches come with comprehensive warranty coverage and ongoing customer support. Whether you need service assistance, warranty claims, or product advice, our team is here to help.

View Warranty Details

Rated Capacity: 3,000 lbs (1360 kg), single-line pull
Motor: 12V DC, 1.5 HP permanent magnet motor
Operation Modes: Wired remote with 12 ft (3.7 m) lead; Wireless remote included
Geartrain: Single-stage planetary
Gear Ratio: 153:1
Clutch: Split ring gear, free-spooling
Brake System: Self-locking gear train (rated load holding)
Durability Enhancements: Tie rods for stability
Rope Type: Synthetic rope, 43 ft × 3/16” (13 m × 4.8 mm)
Fairlead: Roller

Speed & Performance Breakdown

12V DC Performance Specs
Line Pull lbs (kgs)	Line Speed ft/min (m/min)	Motor Current (Amps)	Rated Line Pull Position lbs (kgs)
0	20.4 (6.2)	31	1 / 4500 (2040)
1000 (454)	14.2 (4.3)	65	2 / 3750 (1700)
2000 (907)	10.9 (3.3)	96	3 / 3510 (1595)
3000 (1360)	7.7 (2.4)	125	4 / 3300 (1500)
4500 (2040)	4.9 (1.5)	175	-

Installation & User Guide

Get the most out of your Scout Pro winch with our step-by-step installation and user guide. Learn how to install, operate, and maintain your winch safely and effectively.

Download Guide
